Hybrid Cycling Technology - Hybrid Cycling Technology is a system that combines electric power with human power to produce the most efficient, powerful and natural E-bike riding experience. It's a seamless extension of a rider's own power that sets Liv and Giant E-bikes apart from other “electric” bicycles. The system consists of four key innovative technologies that work in unison with your own body's power output-a seamless extension of your own capabilities.
EnergyPak - EnergyPak side release design makes it easy to handle and remove the battery from the E-bike, plus the battery can be charged on or off the bike for convenience.
SyncDrive Pro - The powerful SyncDrive Pro 2 Motor was co-developed with Yamaha and is their lightest ever E-bike motor. It provides 85Nm of torque, the most in the Amiti E+ range, and will help you confidently conquer the steepest of hills. The Smart Assist mode uses six sensors to optimize your power support automatically. It provides seamless acceleration and a power boost exactly when you need it. With this powerful yet quiet motor underneath you, you'll feel naturally strong in any riding situation and at any speed.
Smart Assist - With Smart Assist you can enjoy seamless acceleration and power boost. The Smart Assist Technology system replicates a natural riding style, using the six sensors to add assistance exactly when needed.
RideControl Go - Available on premium Liv E-Bikes, RideControl Go features a multipurpose button integrated into the top tube. Colored LEDs allow you to switch power modes from the top tube and keep a clean handlebar setup. The lights also display battery level and support mode.
Specifications:
Motor SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technologyController RideControl Ergo3, grip integrated remote
Display RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, EnergyPak Plus 200 range extender compatible
Charger EnergyPak 4A smart charger, 60% in 1:45
Connectivity RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes XS, S, M
Colours Airglow/Black
Frame Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system MX (front 29", rear 27.5")
Fork Fox 36 Performance Elite Live Valve, 150mm travel, 44mm offset, Grip2 damper, Boost 110x15QR, electronic adaptive suspension, e-bike integrated, e-bike integrated
Shock Fox Float X Live Valve, 185x52.5mm Trunnion mount, electronic suspension, e-bike integrated
Handlebar Giant Contact SLR Trail, carbon, 760mm (XS-S), 800mm (M)
Grips Liv Tactal Pro-E Single Lock-On Grips
Stem Giant Contact SLR Trail, integrated, 40/45/50mm Reach, 7/9degree Sweep Adjust System
Seatpost Tranz-X Rad+ dropper, 30,9mm, 30mm travel adjustable (XS/S:90-125mm, M:120-150mm)
Saddle Liv Sylvia E+
Pedals n/a
Shifters SRAM AXS Rocker Paddle, wireless electronic shifting
Front Derailleur MRP 1X HD2 custom co-molded chain guide
Rear Derailleur SRAM GX Eagle AXS
Brakes SRAM Code R, hydraulic disc, 220mm[F] /200mm[R]
Brake Levers SRAM Code R
Cassette SRAM XG-1275, 10-52T, 12-speed
Chain SRAM GX Eagle PowerLock
Crankset Praxis Performance Carbon e-crank arms (XS/S:160, M:165) SRAM X-SYNC Eagle 36T chain ring
Bottom Bracket n/a
Rims TRX 2 Hookless Clincher, 29" [F] / 27.5" [R], 30mm inner width
Hubs TRX 2 MTB Alloy Hub, 6 Bolt, Pawl Driver (3 Pawl 30T) SRAM XD, 110 x 15 [F] / 148 x 12 [R] Thru-axle
Tyres Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F] Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
Extras Tubeless kit (liquid, valves, levers, manual, tool)
