Hybrid Cycling Technology - Hybrid Cycling Technology is a system that combines electric power with human power to produce the most efficient, powerful and natural E-bike riding experience. It's a seamless extension of a rider's own power that sets Liv and Giant E-bikes apart from other “electric” bicycles. The system consists of four key innovative technologies that work in unison with your own body's power output-a seamless extension of your own capabilities.
EnergyPak - EnergyPak side release design makes it easy to handle and remove the battery from the E-bike, plus the battery can be charged on or off the bike for convenience.
SyncDrive Pro - The powerful SyncDrive Pro 2 Motor was co-developed with Yamaha and is their lightest ever E-bike motor. It provides 85Nm of torque, the most in the Amiti E+ range, and will help you confidently conquer the steepest of hills. The Smart Assist mode uses six sensors to optimize your power support automatically. It provides seamless acceleration and a power boost exactly when you need it. With this powerful yet quiet motor underneath you, you'll feel naturally strong in any riding situation and at any speed.
Smart Assist - With Smart Assist you can enjoy seamless acceleration and power boost. The Smart Assist Technology system replicates a natural riding style, using the six sensors to add assistance exactly when needed.
RideControl Go - Available on premium Liv E-Bikes, RideControl Go features a multipurpose button integrated into the top tube. Colored LEDs allow you to switch power modes from the top tube and keep a clean handlebar setup. The lights also display battery level and support mode.
Specifications:
Motor SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technologyController RideControl Ergo3, grip integrated remote
Display RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, EnergyPak Plus 200 range extender compatible
Charger EnergyPak 4A smart charger, 60% in 1:45
Connectivity RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes XS, S, M, L
Colours Soap Suds/Aged Denim
Frame Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system MX (front 29", rear 27.5")
Fork Fox 36 Float Performance, 150mm travel, 44mm offset, Grip Damper, Boost 110x15QR, e-optimised
Shock Fox Float DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
Handlebar Giant Contact 35 Trail, 35x 760mm (XS-S), 780mm (M-L)
Grips Liv Tactal Pro-E Single Lock-On Grips
Stem Giant Contact SL 35
Seatpost Giant Contact Switch, dropper, 30,9mm (XS-S: 100/ M:125/ L:150)
Saddle Liv Sylvia E+
Pedals n/a
Shifters Shimano SLX
Front Derailleur MRP HD2 co-moulded chain guide
Rear Derailleur Shimano Deore SLX, 12-speed, Shadow+
Brakes Shimano SLX BR-M7120, 4-piston, hydraulic disc, 203mm
Brake Levers Shimano Deore SLX, I-spec EV
Cassette Shimano CS-M6100-12, 10-51T, 12-speed
Chain KMC e.12 Turbo, EcoProteq, e-bike optimised
Crankset Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (XS/S:160, M/L:165)
Bottom Bracket n/a
Rims Giant AM 29" [F]/ 27.5" [R], Tubeless ready, 30mm inner width, e-bike optimised
Hubs Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes Sapim E-Lite [R] Race [F], e-bike optimised
Tyres Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F] Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
Extras Tubeless kit (liquid, valves, levers, manual, tool)
