Specifications:
Sizes 27.5": XS,S,M 29": S,M,LColours Milky Way
Frame ALUXX-Grade Aluminum, disc
Fork SXC32-2 RL, air spring, hydraulic lock out, QR, alloy steerer XS: 80mm travel (27.5) S: 100mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (29)
Shock
Handlebar Giant Connect Trail, 31.8mm XS: 670mm (27.5) S: 670mm (27.5) / 670mm (29) M: 750mm (27.5) / 750mm travel (29) L: 750mm (29)
Grips Giant Sole-O
Stem Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (27.5) / 50mm travel (29) L: 50mm (29)
Seatpost Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (29)
Saddle Liv Sport
Pedals MTB platform
Shifters Shimano Deore M4100, 1x10
Front Derailleur
Rear Derailleur Shimano Deore M5120
Brakes Tektro HDC TKD 149, hydraulic, Tektro rotors [F]180mm, [R]160mm
Brake Levers Tektro TKD 149
Cassette Shimano Deore M4100, 11x42
Chain KMC X10
Crankset ProWheel Charm, 30t XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (27.5) / 170mm travel (29) L: 175mm (29)
Bottom Bracket ProWheel cartridge
Rims Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs alloy, sealed bearing
Spokes Stainless steel
Tyres Kenda Booster 27.5 or 29x2.4", wire bead
Extras
Fender/Chainguard Compatible with our clip on mudguards for mountain bikes. For more complete or full-length mudguard solutions, please speak to your local Liv retailer.
Max Tyre Clearance 2.4"
